| Availability: | |
|---|---|
| Quantity: | |
| 24V AGV series | |||||||
| Voltage/capacity | Battery Type | Range of voltage | Current of charge | Mode of communication | Mode of communication | Size/mm | Weight/kg |
| 24V20Ah | NCM | 19.0V~29.4V | 10A | 20A | RS485 | 200*155*80 | 4 |
| 24V30Ah | LFP | 19.0V~29.4V | 15A | 30A | RS485 | 320*190*85 | 8.5 |
| 24V40Ah | LFP | 20.0V~29.4V | 40A | 60A | RS485 | 320*240*85 | 10 |
| 24V50Ah | LFP | 20.0V~29.4V | 50A | 60A | RS485 | 350*240*85 | 11 |
| 24V60Ah | LFP | 20.0V~29.4V | 60A | 100A | RS485/CAN | 460*240*85 | 13.5 |
| 24V100Ah | LFP | 20.0V~29.4V | 100A | 200A | RS485/CAN | 500*190*155 | 24 |
| 24V200Ah | LFP | 20.0V~29.4V | 100A | 200A | RS485/CAN | 480*190*350 | 43 |
| 24V AGV series | |||||||
| Voltage/capacity | Battery Type | Range of voltage | Current of charge | Mode of communication | Mode of communication | Size/mm | Weight/kg |
| 24V20Ah | NCM | 19.0V~29.4V | 10A | 20A | RS485 | 200*155*80 | 4 |
| 24V30Ah | LFP | 19.0V~29.4V | 15A | 30A | RS485 | 320*190*85 | 8.5 |
| 24V40Ah | LFP | 20.0V~29.4V | 40A | 60A | RS485 | 320*240*85 | 10 |
| 24V50Ah | LFP | 20.0V~29.4V | 50A | 60A | RS485 | 350*240*85 | 11 |
| 24V60Ah | LFP | 20.0V~29.4V | 60A | 100A | RS485/CAN | 460*240*85 | 13.5 |
| 24V100Ah | LFP | 20.0V~29.4V | 100A | 200A | RS485/CAN | 500*190*155 | 24 |
| 24V200Ah | LFP | 20.0V~29.4V | 100A | 200A | RS485/CAN | 480*190*350 | 43 |
